Name: 2026 Orbea Occam SL H10
SKU: 9952058736960
Availability: InStock

Description

Key Features

Orbea Occam Hydro aluminum frame, featuring Asymmetric design and Concentric Boost rear axle.
Integrated OC Squidlock MC20 Remote controls suspension lockout and dropper post from a single lever.
Performance suspension handled by the Fox 36 Float SL Performance 140 fork and Fox Float Performance shock with remote lockout.
Reliable Shimano SLX/XT 1×12-speed drivetrain with a wide-range 10-51t cassette.
Strong stopping power from Shimano M6100 Hydraulic Disc Brakes.
Aggressive Maxxis tire pairing: Dissector (front, 3C MaxxTerra Exo) and Rekon (rear, Dual Exo TR).
Durable Race Face AR 30c Tubeless Ready wheelset.
Features the Pure Trail geometry with a slack 65.5° head tube angle and steep 78° seat tube angle.
Frame supports internal cable routing and includes Accessories Containers for storage.

Frame	Orbea Occam Hydro. Concentric Boost 12×148 rear axle. Pure Trail geometry. Both Internal & External cable routing. Asymmetric design. 29″ wheels. Linkage compatible with OC multitool
Rear Shock	Fox Float Performance Remote Push-lock Evol custom tune 210x50mm
Rear Travel	140mm (Assumed from 210x50mm shock/140mm fork context)
Fork	Fox 36 Float SL Performance 140, Grip, Remote Push-lock, QR15x110
Fork Travel	140mm
Remote Lockout	OC Squidlock MC20 Remote, Dropper, Suspension 2 Pos
Head Tube Diameter	1-1/2″ (Steerer tube: FSA 1-1/2″ Integrated Aluminium Cup)
Handlebar	OC Mountain Control MC30, Rise 20, 800mm Width
Stem	OC Mountain Control MC20, 0º
Grips	OC Lock On
Brakes	Shimano M6100 Hydraulic Disc (Deore)
Rotors	(Not specified, typically 180mm/203mm)
Drivetrain	1x
Shifters	Shimano SLX M7100 I-Spec EV, 12-speed
Rear Derailleur	Shimano XT M8100 SGS Shadow Plus, 12-Speed
Crankset	Race Face Aeffect, 32t
Bottom Bracket	(Assumed Race Face Cinch compatible)
Chain	Shimano M6100 (Deore), 12-speed
Cassette	Shimano CS-M7100 (SLX), 10-51t, 12-Speed
Wheels	Race Face AR 30c Tubeless Ready
Front Tire	Maxxis Dissector 2.40″ 60 TPI 3C MaxxTerra Exo TLR
Rear Tire	Maxxis Rekon 2.40″ FB 60 TPI Dual Exo TR
Saddle	Fizik Terra Ridon X5 145mm
Seatpost	OC Mountain Control MC22, 31.6mm, Dropper
Seatpost Lever	(Integrated into OC Squidlock MC20 remote)
Rear Dropout / Hub Dimensions	12mm x 148mm (Concentric Boost)
Miscellaneous	Asymmetric design, Internal & External cable routing, Accessories Containers for storage

Size	SM	MD	LG	XL
Top Tube Length	570mm	596mm	622mm	649mm
Head Tube Angle	65.5°	65.5°	65.5°	65.5°
Head Tube Length	95mm	100mm	110mm	120mm
Seat Tube Angle	78°	78°	78°	78°
Seat Tube Length	405mm	415mm	430mm	460mm
Bottom Bracket Height	341mm (37mm drop)	341mm (37mm drop)	341mm (37mm drop)	341mm (37mm drop)
Chainstay Length	440mm	440mm	440mm	440mm
Wheelbase	1191mm	1218mm	1245mm	1276mm
Reach	440mm	465mm	490mm	515mm
Stack	611mm	615mm	624mm	633mm
Additional Info	All specifications listed are with 140mm travel fork with 554mm axle-to-crown length and 44mm offset.

mycustom	Color#Cinnamon, Spaceship Green, Tanzanite~Size#Small, Medium, Large, XL
