Liv Alight Disc 2

Original price was: $850.00.Current price is: $170.00.

Color:

Size:

SKU: 8259805806628 Category:

Description

The Alight Disc features an easy on and off frame design, touchpoints to maximize comfort and is available in Alight Disc City models equipped with fenders, a rack and a kickstand making the ride on the bike path or the commute to work more enjoyable.

Key Performance Factors

Versatility

Run errands easily with the Alight’s included fenders, rear rack, and kickstand (select models).

Comfort

Staying comfortable on your rides around town is a non-negotiable, so the Alight has an easy on and off frame, and comes with shock-absorbing grips, a pressure-relieving saddle, and a suspension seatpost.

Control

The Alight’s powerful disc brakes work in dry or wet conditions, and with the increased fork clearance, you can install up to a 40c tire which allows for greater traction.

Techs & Features

Sizing Guide and Geometry

Sizing to be used as a reference only. Please check with a local authorized Liv or Giant dealer to determine the correct size.
Available sizes may vary from country to country.

Selection of a button will change the units measurement displayed throughout the entire sizing guide section.

  • XS
    4’10”5’4”
  • S
    5’2”5’7”
  • M
    5’5”5’9”
  • L
    5’7”6’0”

Selection of a button will change the units measurement displayed throughout the entire sizing guide section.

  XS S M L
A Seat Tube Length (inch) 14.6 16.5 18.1 19.7
B Seat Tube Angle 73.5° 73.5° 73.0° 73.0°
C Top Tube Length (inch) 21.1 21.7 22.4 23.2
D Head Tube Length (inch) 5.1 5.9 6.3 6.9
E Head Tube Angle 70.0° 70.5° 71.0° 71.0°
F Fork Rake (inch) 2 2 2 2
G Trail (inch) 3.1 2.9 2.8 2.8
H Wheelbase (inch) 41.1 41.5 41.9 42.7
I Chain Stay Length (inch) 17.5 17.5 17.5 17.5
J Bottom Bracket Drop (inch) 2.4 2.4 2.4 2.4
K Stack (inch) 21.8 22.6 23.1 23.7
L Reach (inch) 14.6 15 15.4 16
M Stand Over Height (inch) 23.3 23.2 23.3 23.1
N Handlebar Width (inch) 23.6 23.6 25.2 25.2
O Stem Length (inch) 3.1 3.1 3.5 3.9
P Crank Length (inch) 6.5 6.5 6.7 6.7
Q Wheel Size 700C 700C 700C 700C
