Description
Frame: CF5 IV – carbon – Premium fibres for lightweight and performance, race geometry.Internal cable routing, 142 x12mm axle standard, flat mount rear brakes with Disc Cooler, 1 1/2″ to 1 1/4″ headtube. Max tyre size – 30c
Fork: Reacto CF5 IV Disc; full carbon, tapered steerer. Max tyre size: 700 x 30c – Disc cooler technology
Headset: FSA ACR 3MM thinner neck
Stem: Vision Metron 5D ACR EVO; carbon – Length – 90mm (XXS-XS), 100mm (S), 110mm (M-L), 120mm (XL)
Handlebar: Vision Metron 5D ACR EVO; carbon; 380mm (XXS-XS-S); 400mm (M-L-XL)
Grip: Merida Expert
Brake Type: Hydraulic disc
Brake Lever: Shimano Ultegra
Front Brake: Shimano Ultegra; Hydraulic disc brake caliper with Shimano CL800; 160mm rotor
Rear Brake: Shimano Ultegra; Hydraulic disc brake caliper with Shimano CL800; 160mm rotor
Front Tyre: Continental Grand Prix 5000S TR; 700 x 28c; Kevlar bead; tubeless ready
Rear Tyre: Continental Grand Prix 5000S TR; 700 x 28C; Kevlar bead; tubeless ready
Wheel Size: 700c
Rim: Part of wheelset – Reynolds BL60 Expert DB,21mm inner rim width; 41mm rim depth; carbon; Tubeless ready (tubeless tape and valves included)
Spokes: Part of wheelset
Front Hub: Part of wheelset – Reynolds BL60 Expert DB, 100 x 12mm;Centerlock;
Rear Hub: Part of wheelset – Reynolds BL60 Expert DB, 142 x 12mm; Centerlock; Shimano HG
Speeds: 24
Front Derailleur: Shimano Ultegra Di2; FD-R8150
Rear Derailleur: Shimano Ultegra Di2; RD-R8150
Shift Levers: Shimano Ultegra Di2
Chain: Shimano CN-M8100-12
Cassette: Shimano CS-R8101; 11-30 teeth; 12 speed
Chainset: Shimano Ultegra; 52-36 tooth chainset ; Crank length – 165mm (XXS), 170mm (XS), 172.5mm (S/M/L), 175mm (XL)
Bottom Bracket: SM-BB72-41B, Pressfit 86.5
Saddle: Scratch M5 with V-mount adapter; includes Merida minitool
Seat Post: Merida Team CW; Aero shape; 15mm layback; Carbon
