| Frame |
CF5 V carbon – Premium fibres for lightweight and performance, race geometry. Internal cable routing, 142 x12mm axle standard, flat mount rear brakes with Disc Cooler, 1 1/2″ to 1 1/4″ headtube. Pressfit 86.5 BB Standard, Max tyre size – 30c |
| Fork |
Scultura CF5 Disc; material: carbon; 700x30C max. tyre size |
| Gears |
24 |
| Shifters |
Front: SRAM Red AXS, Rear: SRAM Red AXS |
| Front Derailleur |
SRAM Red AXS |
| Rear Derailleur |
SRAM Red AXS E1 |
| Bottom Bracket |
SRAM Pressfit Dub; Pressfit 86.5 |
| Chain |
SRAM Red E1 |
| Chainset |
SRAM Red AXS; 50-37 tooth chainset; Power Meter; Crank length: XXXS – 160mm, (XXS-XS) – 165mm, (S-M) – 170mm, (L-XL) – 172.5mm |
| Cassette |
SRAM XG 1290 E1; 10-36 teeth; 12 speed |
| Brake Lever |
SRAM Red AXS |
| Front Brake |
SRAM Red AXS; Hydraulic disc with SRAM Paceline X Centerlock; 160mm |
| Rear Brake |
SRAM Red AXS; Hydraulic disc with SRAM Paceline X Centerlock; 160mm |
| Grip |
Merida Road Expert |
| Handlebar |
Merida Team SL 1P Integrated; material: carbon; (XXXS-S) – 380mm wide, (M-L) – 400mm wide, XL – 420mm wide |
| Stem |
Merida Team One-Piece Integrated; material: carbon; Length: (XXXS-XS) – 90mm, S – 100mm, (M-L) – 110mm, XL – 120mm |
| Head Set |
Merida Team SL (OP-203 neck) |
| Pedal |
Not included |
| Saddle |
Prologo Nago R4 PAS; Nack |
| Seat Post |
Metron RS Seatpost; 27.2mm diameter; in-line; material: carbon |
| Wheel Size |
700c |
| Rims |
Zipp WH-353-NSW Tubeless; 12x100mm; 12x142mm; 25mm inner rim width; Centerlock; SRAM XDR; carbon |
| Spokes |
Part of wheelset – Zipp WH-353-NSW Tubeless |
| Front Hub |
Part of wheelset – Zipp WH-353-NSW Tubeless |
| Rear Hub |
Part of wheelset – Zipp WH-353-NSW Tubeless |
| Front Tyre |
Schwalbe Pro One Aero; Super Race; RaceGuard; 700x28C |
| Rear Tyre |
Schwalbe Pro One Aero; Super Race; RaceGuard; 700x28C |
| Colour |
Silk Blue/Grey (Flash Bcp) |
| Season |
2026 |
| Other |
Garmin Carrier + Garmin insert*2 + GoPro/Light Mount and bottle cage |
