Description
Bike Geometry
- Bottom Bracket Drop: 67 mm
- Chain Stay Length: 405 mm
- Fork Offset: 368 mm
- Fork Total Length: 50 mm
- Head Tube Angle: 73°
- Head Tube Length: 140 mm
- Reach: 393 mm
- Stack: 538 mm
- Seat Tube Angle: 74°
- Seat Tube Length: 490 mm
- Top Tube Length: 547 mm
- Wheelbase: 989 mm
Brake System
- Front Brake: Shimano Ultegra R8170, 160 mm (Hydraulic Disc)
- Rear Brake: Shimano Ultegra R8170, 140 mm (Hydraulic Disc, Flat Mount)
Drivetrain
- Bottom Bracket: Shimano BB72-41B (PressFit)
- Cassette: Shimano Ultegra CS-R8100-12, HG+, 11–34T
- Chain: Shimano CN-M7100, 12-speed
- Crankset: Shimano Ultegra FC-R8150, 52–36T (Double)
- Front Derailleur: Shimano Ultegra Di2 R8150, Brazed-On
- Rear Derailleur: Shimano Ultegra Di2 R8150, 12-speed
- Shifters: Shimano Ultegra ST-R8170 (Shift/Brake Levers)
- Number of Gears: 24
- Pedals: VP 335 Clips & Strap
Frame & Fork
- Frame Size: 49 cm (M)
- Max Load: 110 kg
- Fork: Lapierre Carbon UD SLI (Non-suspension)
Cockpit & Saddle
- Handlebar: Lapierre Carbon Aero, Drop 130 mm, Reach 70 mm, Flare 5° (Drop Bar)
- Stem: Lapierre Alloy, Semi-internal Routing, -10°, Ø 31.8 mm, L: 100 mm
- Headset: Acros Integrated
- Saddle: Prologo Dimension T4.0 Rails
- Seatpost: Lapierre Carbon Xelius DRS, 0 mm Offset, L: 350 mm (Non-suspension)
- Grips: Lapierre
Wheels & Tyres
- Wheelset: DT Swiss ER1600 Spline 30 mm, Centerlock, Tubeless Compatible (Aluminium)
- Rear Wheelset: DT Swiss ER1600 Spline 30 mm, Centerlock, Tubeless Compatible, HG Driv
- Tyres: Schwalbe One Performance, RaceGuard, MicroSkin (Front & Rear)
- Tyre Size (ETRTO): 25-622
- Wheel Size: 28” (Front & Rear)
